Separate powered edge ports from optical uplinks when ordering Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX
Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX, part number 942170048, combines eight 10/100BASE-TX PoE+ ports with four 100/1000 Mbit/s SFP positions. The page therefore treats powered-device demand and optical-module selection as two linked but separately documented parts of the bill of materials.
Map each physical interface before configuring traffic
Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX divides twelve physical interfaces into eight 10/100BASE-TX RJ45 PoE+ ports and four 100/1000 Mbit/s SFP positions. The copper side can connect and power suitable field devices, while the optical side can carry traffic toward another cabinet or network zone. Keep those roles separate in the port schedule: an SFP position is not an extra powered copper connection, and the actual fiber reach depends on the transceiver selected for that position.
Assign the powered endpoints first, then reserve the four optical positions for the paths defined by the network drawing. Record which ports are intended for cameras, wireless equipment or other powered devices, but confirm each endpoint's IEEE 802.3at compatibility and demand from its own data. The official port description is the boundary for this product page; it does not prove compatibility with an unspecified field device. For the BRS32-8TX/4SFP ports review, retain this evidence with part number 942170048 and the complete ordering code.
Eight powered ports do not remove the need for a power budget
Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX provides eight PoE+ ports and the catalog lists up to 240 W of PoE power. Build the endpoint schedule from actual powered-device data: record the required standard, expected demand, cable path and startup behavior for each connection. The maximum budget is a ceiling for planning, not a statement that every endpoint consumes the same amount.
Add the planned loads, retain design margin and consider simultaneous startup where the endpoint documentation makes it relevant. If the full 240 W is not required, document the accepted smaller load rather than leaving the design implicit. The resulting schedule supports power-source selection, commissioning and later expansion decisions. For the BRS32-8TX/4SFP poe review, retain this evidence with part number 942170048 and the complete ordering code.
Turn the SFP positions into a complete fiber bill of materials
The four SFP slots on Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX do not define a universal connector, wavelength, fiber type or transmission distance. Each link needs a compatible module at both ends, an accepted operating rate and an optical budget that accounts for the installed path. List the required transceiver references and quantities separately from part number 942170048 so the quotation makes the optical supply scope visible.
Check the far-end equipment, patch-panel connectors and available fiber before choosing modules. Record each fitted module in the equipment schedule and retain that list with the switch configuration. During fault finding, SFP management can provide interface evidence, but physical inspection and link-budget review remain relevant when a fiber path is unstable or unavailable. For the BRS32-8TX/4SFP optical review, retain this evidence with part number 942170048 and the complete ordering code.
| Complete product code | Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX |
|---|---|
| Catalog Type | BRS32-8TX/4SFP |
| Part Number | 942170048 |
| Port configuration | 12 Ports in total: 8x 10/100BASE TX / RJ45; 4x 100/1000Mbit/s fiber ; 8 x PoE(+) Ports (phantom power) ; 1. Uplink: 2 x SFP Slot (100/1000 Mbit/s) ; 2. Uplink: 2 x SFP Slot (100/1000 Mbit/s) |
| Operating voltage | 2 x (48 VDC (PoE)/ 54 VDC (PoE+)) |
| Power consumption | max. 250 W with 240W PoE |
| Operating temperature | 0-+60 °C |
| Housing / mounting / protection | PC-ABS / DIN rail / IP30 |
| Dimensions / weight | 73 mm x 138 mm x 115 mm / 550 g |
| Optical module scope | Four SFP positions are documented; compatible transceivers must be specified separately. |
| PoE planning boundary | Eight PoE+ ports; maximum 240 W PoE budget stated in the manufacturer record. |
Stock/reference image for a Hirschmann BOBCAT switch. Match BRS32-8TX/4SFP by code and part number before ordering.
Document the ring or coupled topology before commissioning
The catalog for Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX lists HIPER-Ring, MRP, RSTP, link backup, LACP and redundant network coupling among the redundancy-related functions. Select the method that matches the approved topology and the capabilities of participating devices; the presence of several functions is not a reason to enable overlapping mechanisms without a defined design.
Acceptance should include a controlled failure test for the chosen arrangement. Record normal forwarding paths, the expected change during a link interruption and the observed recovery. Save the accepted settings with the full product code so later maintenance can distinguish an intended redundancy event from an unexplained topology change. For the BRS32-8TX/4SFP redundancy review, retain this evidence with part number 942170048 and the complete ordering code.
Move from label inspection to tested network behavior
Commission Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX in a sequence that can be audited and repeated. Begin with the delivered label, part number and physical condition, then verify the DC supply arrangement and cabinet installation. Establish the authorized management path before applying VLAN, redundancy or access-control settings.
- Label RJ45 and optical destinations according to the approved port schedule.
- Confirm negotiated rate and duplex on copper ports; verify fitted SFP references separately.
- Test the selected redundancy behavior with the participating network devices.
- Save the accepted configuration and record the software information used at handover.
Retain the acceptance record with the full code rather than a shortened family label. That gives a future replacement team the hardware identity, topology, settings and observed normal condition needed to restore service deliberately. For the BRS32-8TX/4SFP commission review, retain this evidence with part number 942170048 and the complete ordering code.
Send a configuration-specific inquiry
Send the exact keyword Hirschmann BRS32-0804OOOO-SPCY99HHSESXX.X.XX, catalog Type BRS32-8TX/4SFP, part number 942170048, quantity and delivery destination. Include the required SFP module references, quantities and far-end connection details. Include the powered-device schedule and accepted PoE budget. State any mandatory management, security, timing or redundancy functions and identify required accessories separately.
Ask the supplier to identify the offered code and scope explicitly. For replacement work, attach a readable nameplate image and the key installed-system details. This creates a quotation that can be compared against the engineering requirement without reducing the request to a generic port count. For the BRS32-8TX/4SFP inquiry review, retain this evidence with part number 942170048 and the complete ordering code.
