Confirming the Full Asco SC8320A196 Valve and Coil Arrangement from the Installed Labels Before a Replacement Is Selected
Asco SC8320A196 is retained as the exact ASCO component inquiry from the product list. A matching primary technical record for this complete designation has not been established, so coil voltage, port size, pressure limits and operating function are not assigned here. The valve-body and coil labels should be reviewed together before an offered assembly is accepted.
Shared reference image associated with the Asco SC8320A196 request. Confirm the actual offered unit and included accessories from the quotation and product labels.
Photograph both identifying labels
For Asco SC8320A196, collect the valve-body marking and the coil identification where accessible under the site procedure. A sourcing request may quote only one of those labels. Keeping both makes it easier to establish whether the intended purchase is a complete assembly or one component fitted to an existing valve.
Product references and application decisions
| Selection point | Confirmed detail or required review |
|---|---|
| Exact product | Asco SC8320A196 |
| Requested designation | SC8320A196 |
| Coil details | Confirm voltage, frequency and complete coil identification |
| Valve function | Confirm from the exact assembly documentation |
| Process suitability | Verify medium, pressure, temperature and materials |
| Supplied scope | Distinguish complete valve, coil and service parts |
Do not infer the coil from a familiar body
The electrical requirements of Asco SC8320A196 should be confirmed directly from the offered execution. Similar valve bodies can be supplied with different coil arrangements. A request for Asco SC8320A196 should therefore state the existing electrical supply and preserve the label evidence instead of assuming that an unsuffixed description determines the coil voltage.
Explain the process connection and function
For Asco SC8320A196, provide the relevant connection drawing and describe what the valve is required to do in the system. Include the medium and applicable operating conditions for technical review. A photograph that establishes physical appearance does not confirm internal function, flow direction or compatibility with the process.
Separate repair parts from a complete replacement
- When asking for Asco SC8320A196, specify whether the valve, coil or another service item is needed.
- List components that will remain installed.
- This prevents a quotation for one repair component from being compared directly with an offer for an entire assembly and helps the receiving team recognize the agreed scope.
Keep alternatives documented
If an exact Asco SC8320A196 is unavailable, ask for an explicit comparison before approving another designation. The comparison should address the function, electrical execution and process connections relevant to the installation. Do not accept a shared series number as sufficient evidence of interchangeability between the offered valve and the existing one.
Make the sourcing record useful for maintenance
- Quote Asco SC8320A196 with quantity, label photographs and the available installation information.
- Ask the supplier to identify unresolved details in the offer.
- Once the intended Asco SC8320A196 assembly has been confirmed, retain that evidence with the asset record so later spare requests do not repeat the same uncertainty about the valve and coil combination.
