Product description：
The outlet filter is used in conjunction with the associated filter fan to dissipate lost heat out of the enclosures, to ventilate the enclosure and to protect temperature-sensitive components. This is done via the direct supply of ambient air that must be below the permissible temperature inside the enclosure.
Article no.: SK 3238300
Version wall-mounted
Benefits Easy filter change thanks to a new opening mechanism on the louvre grille
Faster assembly on the enclosure due to optimized snap hooks：Tool-free mounting
Material：Plastic
Color：RAL 7035
Supply includes：Outlet Filters Pleated filter
Mounting cut-out：
Width of opening: 124 mm
Cut-out height: 124 mm
( Width of opening: 4.88 ˝
Cut-out height: 4.88 ˝ )
Suitable for Model No.SK 3238.7xx
Dimensions：
Width: 148.5 mm
Height: 148.5 mm
Depth: 34.2 mm
( Width: 5.85 ˝
Height: 5.85 ˝
Depth: 1.35 ˝ )
Protection category NEMA
Type 12 with chopped fiber filter/pleated filter
Type 3, 3R, 4, 4X with chopped fiber filter/pleated filter and hose-proof hood
Protection category IP to IEC 60 529
IP 54 with chopped fiber filter/pleated filter
IP 55 with pleated filter and absorber mat
IP 56 with chopped fiber filter/pleated filter and hose-proof hood
