Do you need good price MOXA EDS-316 16-port unmanaged Ethernet switches high quality and good performance? Send an email and we will offer the best price for you.

Product description:

The EDS-316 Ethernet switches provide an economical solution for your industrial Ethernet connections. These 16-port switches come with a built-in relay warning function that alerts network engineers when power failures or port breaks occur. In addition, the switches are designed for harsh industrial environments, such as the hazardous locations defined by the Class I Div. 2 and ATEX Zone 2 standards.

The switches comply with FCC, UL, and CE standards and support either a standard operating temperature range of -10 to 60°C or a wide operating temperature range of -40 to 75°C. All switches in the series undergo a 100% burn-in test to ensure that they fulfill the special needs of industrial automation control applications. The EDS-316 switches can be installed easily on a DIN rail or in a distribution box.

0/100BaseT(X) Ports (RJ45 connector)

EDS-316 models: 16

EDS-316-MM-SC/MM-ST/MS-SC/SS-SC models: 14

EDS-316-SS-SC-80 models: 14

EDS-316-M-SC/M-ST/S-SC models: 15

All models support:

Auto negotiation speed

Full/Half duplex mode

Auto MDI/MDI-X connection

100BaseFX Ports (multi-mode SC connector)

EDS-316-M-SC models: 1

EDS-316-MM-SC models: 2

EDS-316-MS-SC models: 1

100BaseFX Ports (multi-mode ST connector)

EDS-316-M-ST models: 1

EDS-316-MM-ST models: 2

100BaseFX Ports (single-mode SC connector)

EDS-316-MS-SC models: 1

EDS-316-S-SC models: 1

EDS-316-SS-SC models: 2

100BaseFX Ports (single-mode SC connector, 80 km)

EDS-316-SS-SC-80 models: 2

Standards

IEEE 802.3 for 10BaseT

IEEE 802.3u for 100BaseT(X) and 100BaseFX

IEEE 802.3x for flow control
