Dear customers, do you need good price Phoenix 2902040 Signal Conditioner? We have Phoenix 2902040 in stock now.Please send an inquiry and we will provide the best price for you.

Phoenix 2902040 product description:

This 3-terminal isolation amplifier uses plug-in connection technology and features calibration measurement range switching. It can be used for electrical isolation of unipolar and bipolar analog signals. Input/output can be configured via DIP switches. It features plug-in connection technology and standard configuration.

This 3-terminal isolation amplifier, employing plug-in connection technology, allows for measurement range switching via DIP switches. It provides electrical isolation, conversion, amplification, and filtering of unipolar and bipolar standard and specification signals. The following standard analog signals are available on the input side: 0...20 mA, 4...20 mA, 0...0 V, 0...5 V, 1...5 V or -10...10 V, and 2...10 V, 0...20 V, 0...24 V, 0...30 V, -5...5 V, -20...20 V, -24...24 V, -30...30 V, and -20...20 mA. The following signals can be provided on the output side: 0...20 mA, 4...20 mA, 0...10 V, 0...5 V, 1...5 V, -10...10 V, and -5...5 V. No adjustment is required after measurement range switching. The measurement transmitter supports fault monitoring and NFC communication.
